处理器

CPU

Intel®Q370

网络

2*RJ45 Intel ®I210-IT/I219-LM GbE LAN (SupportsWoL, Teaming, Jumbo Frame & PXE)

内存

2*DDR4-2400/2666 MHz SO-DIMM Sockets, Supports up to 64 GB (Un-buffered and Non-ECC Type)

显示

Triple Independent Display

1*DVI-I DVI-D: resolution up to 1920 x 1200 @ 60Hz

VGA: resolution up to 1920 x 1080 @ 60Hz

2*DP DP: resolution up to 4096 x 2304 @ 60Hz

储存

2*2.5"SATA HDD/SSD bay (Gen3), 1*Internal, 1* FrontAccessable Supports RAID0/1

3*mSATA(sharedby Mini-PCIesocket) (Gen3),BIOSSelectable

1*M.2 Key M 2280 Socket, Supports PCIe x4 NVMe SSD or SATA SSD (Gen3)

串口

2*RS-232/422/485 with Auto Flow Control (Supports 5V/12V), DB9

USB

2*USB 3.1 Gen2(TypeA)

4*USB 3.0(TypeA)

2*USB 2.0(TypeA)

扩展插槽

3*Full-size Mini-PCIe Socket

2*SIM Socket

1*CFM (Control Function Module) Interface

2*CMI (Combined Multiple I/O) High Speed Interface

2*CMI (Combined Multiple I/O) Low Speed Interface

2*AntennaHole

4*Universal I/O Bracket

电源

Supports 9~48VDC，AT/ATX Power Type

外形尺寸

ECW-1200: 227mm x 86mm x 261mm (W x H x D)

ECW-1201: 227mm x 106mm x 261mm (W x H x D)

ECW-1202: 227mm x 126mm x 261mm (W x H x D)

工作环境

Temperature

工作温度:35W TDP Processor:-40°C~70°C 51~65W TDP Processor: -40°C~45°C

存储温度：-40~85°C

安装方式

Wall固定支架 - 支架与螺丝

可选功能模组

LAN

Optional CMI Module

- 4x RJ45 GbE LAN Module

- 4x M12 GbE LAN Module

PoE+

Optional CMI & CFM Module

- 4x PoE+, Individual port 25.5W, RJ45 Port

- 4x PoE+, Individual port 25.5W, M12 Port

Serial Port

Optional CMI Module

- 4x Isolated COM Module

- 4x COM Module

* Supports RS-232/422/485 with Auto Flow Control, 5V/12V, DB9

Isolated DIO

Optional CMI Module

- 16x Optical Isolated DIO Module (8 in/8 out)

Power Adapter

Optional AC/DC Adapter

- AC/DC 24V/5A, 120W

- AC/DC 24V/9.2A, 220W
