处理器

CPU

Intel Atom® x7-E3950 Processor, Quad Core, 2M Cache, 1.6GHz (2.0GHz), 12W

网络

2*Intel®I210ATPCIe(10/100/1000Mbps)

内存

8GBMemoryOnboardDualChannelLPDDR42400MHz

显示

1*VGA/DVI-D

VGA: resolution up to 1920x1200 @ 60Hz

DVI-D: resolution up to 1920x1200 @ 60Hz

2*Mini-DP/Micro-HDMI

Mini-DP: resolution up to 4096x2160 @ 60Hz

Micro-HDMI: resolution up to 3840x2160 @ 30Hz

串口

1*RS-232/422/485 (DB-9)

1*DB9 RS-232/422/485 (default), or change to 8-bit DIO by jumper select

USB

2*USB 3.0 (type A)

2*USB 2.0 (type A)

DIO

1*8-bit DIO or DB9 RS-232/422/485

扩展插槽

1*Full-size Mini PCIe (PCIe/USB/SATA)

1*M.2 (2242 B Key) (PCIe/USB/SATA)

1*M.2 (2230 E Key) (PCIe/USB)

电源

Wide Range 9~36V DC Jack

外形尺寸

161mm x 35.1mm x 108.2mm (W x H x D)

工作环境

Temperature

工作温度:-20~60°C (standard),-40~70°C (wide-temp)

With 0.4m/s Air Flow

存储温度：-40~85°C

安装方式

Wall固定支架 - 支架与螺丝(标配)

VESA/DIN Rail固定支架 - 支架与螺丝(选配)
