Part Number

PCIE-1802-AE

PCIE-1802L-AE

General

Power Consumption

Typical: 3.3V @ 400 mA , 12V @ 850 mA

Typical: 3.3V @ 400 mA , 12V @ 850 mA

OS Support

32-bit/64-bit Windows 7/8/10, and Linux

32-bit/64-bit Windows 7/8/10, and Linux

Dimensions

168 x 99 mm ( 6.6 x 3.9in.)

168 x 99 mm ( 6.6 x 3.9in.)

Bus

PCIe

PCIe

I/O Connectors

1 × 36-pin VHDCI (mini-SCSI), and 1 × HDMI

1 × 36-pin VHDCI (mini-SCSI), and 1 × HDMI

Operating Temperature

0 ~ 60° C (32 ~ 140° F)

0 ~ 60° C (32 ~ 140° F)

Programming Language

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

Analog Input

Sampling Rates(S/s)

216 K

216 K

Bipolar Inputs (V)

±10, 5, 2, 1, 0.5,0.2

±10, 5, 2, 1, 0.5,0.2

Channels

8

4

Type

Simultaneous Sample

Simultaneous Sample

Resolution(Bits)

24

24

Trigger Mode

Start, delay to start, stop, or delay to stop trigger

Start, delay to start, stop, or delay to stop trigger

Overvoltage Protection

±24 V

±24 V
