Part Number

UNO-3483G-374AE

General

Mounting

Enclosure mounting

Power Consumption

50W (Typical), 100W (Max)

Certifications

CE, FCC, UL, BSMI

Enclosure

Aluminum Housing

OS Support

WIN7/8, WES7, WES-2009, Linux

Weight (Net)

4.9kg (10.8lbs)

Power Requirement

12V/24VDC ± 20%

Dimensions ( W x D x H )

305 x 82 x 225 mm (12'' x 3.2'' x 8.9'')

System Hardware

Memory

Built-in 8GB DDR3L 1333 MHz

Storage

One mSATA slot, Two built-in 2.5" SATA HDD brackets with support for RAID 0/1.(Compatible with 9.5mm height HDD)

Watchdog Timer

Programmable 255 levels timer interval, from 1 to 255 sec

BIOS

AMI UEFI 128Mbit Flash BIOS

Expansion

1 x PCIex4, 2 x Full-size mPCIe, 1 x half-size mPCIe

Processor

Intel® Core™ i7-3612QE QC 2.1GHz Ivy Bridge Quad Core, 6MB L2

System Chip

Integrated Intel 8 Series Chipset

Graphics Engine

Intel® HD Graphics

Ethernet

LAN A: Intel® 82579LM GbE, Intel® AMT, IEEE802.1AS, 802.3az, LAN B: Intel® 82583V GbE, IEEE802.1AS, 802.3az

LED Indicators

LEDs for Power, battery, LAN (Active, Status), COM (Tx/Rx) and HDD

I/O Interface

Serial Ports

1 x RS-232, DB9, 50~115.2kbps (pin header), 1 x RS-422/485, DB9, auto flow control, 50~115.2kbps (pin header)

Audio

Mic-in, Line-In, Line-Out (Pin Header)

USB Port

4 x USB Ports (2 x USB2.0, 2 x USB3.0 compliant)

Displays

1 x VGA, supports 1920 x 1080 @ 60Hz 24bpp, 1 x HDMI 1.4a, supports 1920 x 1080 @ 60Hz 24bpp

Power Connector

1x 7 Pins, Terminal Block to support dual power input and remote power control

LAN Ports

2 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

Environment

Relative Humidity

10 ~ 95% @ 40°C non-condensing

Ingress Protection

Integrated seals maintain with IP67 design

Vibration Protection

Operating, IEC 60068-2-64, 2Grms, random, 5 ~ 500Hz, 1hr/axis (mSATA)

Shock Protection

Operating, IEC 60068-2-27, 50G, half sine, 11ms

Operating Temperature

- 20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow (Industry SSD)

Storage Temperature

-40 ~ 85°C (-40~185°F)
