Part Number

UNO-3283G-634AE

UNO-3283G-6541AE

UNO-3283G-654AE

Environment

Operating Temperature

-20 ~ 60°C (-4 ~ 140°F) with 0.7m/s airflow environment 0~50°C (32 ~ 122°F) for UNO-3283G-6541AE

-20 ~ 60°C (-4 ~ 140°F) with 0.7m/s airflow environment 0~50°C (32 ~ 122°F) for UNO-3283G-6541AE

-20 ~ 60°C (-4 ~ 140°F) with 0.7m/s airflow environment 0~50°C (32 ~ 122°F) for UNO-3283G-6541AE

Relative Humidity

10 ~ 95% RH @ 40°C, non-condensing

10 ~ 95% RH @ 40°C, non-condensing

10 ~ 95% RH @ 40°C, non-condensing

Vibration Protection

Operating, IEC 60068-2-64, 4Grms, random, 5 ~ 500Hz, 1hr/axis (SSD); 1.5Grms, random, 5 ~ 500Hz, 1hr/axis (HDD)

Operating, IEC 60068-2-64, 4Grms, random, 5 ~ 500Hz, 1hr/axis (SSD); 1.5Grms, random, 5 ~ 500Hz, 1hr/axis (HDD)

Operating, IEC 60068-2-64, 4Grms, random, 5 ~ 500Hz, 1hr/axis (SSD); 1.5Grms, random, 5 ~ 500Hz, 1hr/axis (HDD)

Shock Protection

Operating, IEC 60068-2-64, 1Grms, random, 5 ~ 500Hz, 1 hr/axis

Operating, IEC 60068-2-64, 1Grms, random, 5 ~ 500Hz, 1 hr/axis

Operating, IEC 60068-2-64, 1Grms, random, 5 ~ 500Hz, 1 hr/axis

Storage Temperature

-40 ~ 85°C ( -40 ~ 185°F)

-40 ~ 85°C ( -40 ~ 185°F)

-40 ~ 85°C ( -40 ~ 185°F)

I/O Interface

Audio

Mic-in, Line-In, Line-Out (Pin Header)

Mic-in, Line-In, Line-Out (Pin Header)

Mic-in, Line-In, Line-Out (Pin Header)

Displays

1 x VGA, supports 1920 x 1080 @ 60Hz 24bpp, 1 x HDMI 1.4a, supports 1920 x 1080 @ 60Hz 24bpp

1 x VGA, supports 1920 x 1080 @ 60Hz 24bpp, 1 x HDMI 1.4a, supports 1920 x 1080 @ 60Hz 24bpp

1 x VGA, supports 1920 x 1080 @ 60Hz 24bpp, 1 x HDMI 1.4a, supports 1920 x 1080 @ 60Hz 24bpp

Power Connector

2 x 3 Pin, terminal Block to support dual power input and relay output

2 x 3 Pin, terminal Block to support dual power input and relay output

2 x 3 Pin, terminal Block to support dual power input and relay output

USB Port

6 x USB 3.0 Ports

6 x USB 3.0 Ports

6 x USB 3.0 Ports

Serial Ports

1 x RS-232, DB9, 50~115.2kbps (pin header), 1 x RS-422/485, DB9, auto flow control, 50~115.2kbps (pin header)

2 x RS-232/422/485 with DB9 connectors RS-485 auto flow control, 50~115.2kbps, 2 x RS-232 (optional pin header)

2 x RS-232/422/485 with DB9 connectors RS-485 auto flow control, 50~115.2kbps, 2 x RS-232 (optional pin header)

LAN Ports

2 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

2 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

2 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet

System Hardware

Memory

Built-in 8GB DDR4 2133 MHz, two socket support up to 32GB (Optional ECC RAM with selected RAM module)

Built-in 8GB DDR4 2133 MHz (Optional ECC RAM with selected RAM module)

Built-in 8GB DDR4 2133 MHz (Optional ECC RAM with selected RAM module)

Processor

Intel Core™ i3-6102E 1.9GHz

Intel Core™ i5-6440EQ

Intel Core™ i5-6442EQ 1.9GHz

Expansion

1 x PCIex16, 1 x PCI, 2 x Full-size mPCIe

1 x PCIex16, 1 x PCI, 2 x Full-size mPCIe

1 x PCIex16, 1 x PCI, 2 x Full-size mPCIe

LED Indicators

LEDs for Power, LAN , Tx/Rx , battery and HDD

LEDs for Power, LAN , Tx/Rx , battery and HDD

LEDs for Power, LAN , Tx/Rx , battery and HDD

Storage

One mSATA slot; One CFast slot (sh) Two built-in 2.5" SATA HDD brackets with support for RAID 0/1. (Compatible with 9.5mm height HDD)

One mSATA slot; One CFast slot (sh) Two built-in 2.5" SATA HDD brackets with support for RAID 0/1. (Compatible with 9.5mm height HDD)

One mSATA slot; One CFast slot (sh) Two built-in 2.5" SATA HDD brackets with support for RAID 0/1. (Compatible with 9.5mm height HDD)

Graphics Engine

Intel® HD Graphics

Intel HD Graphics 100 series

Intel® HD Graphics

BIOS

AMI UEFI 128Mbit Flash BIOS

AMI UEFI 128Mbit Flash BIOS

AMI UEFI 128Mbit Flash BIOS

System Chip

Integrated Intel 100 Series Chipset

Integrated Intel 100 Series Chipset

Integrated Intel 100 Series Chipset

Watchdog Timer

Programmable 255 levels timer interval, from 1 to 255 sec

Programmable 255 levels timer interval, from 1 to 255 sec

Programmable 255 levels timer interval, from 1 to 255 sec

Ethernet

LAN A: Intel® i210-IT GbE, IIEEE802.1AS, 802.3az, LAN B: Intel® i219-LM GbE, Intel® AMT, IEEE802.1AS, 802.3az

LAN A: Intel® i210-IT GbE, IIEEE802.1AS, 802.3az, LAN B: Intel® i219-LM GbE, Intel® AMT, IEEE802.1AS, 802.3az

LAN A: Intel® i210-IT GbE, IIEEE802.1AS, 802.3az, LAN B: Intel® i219-LM GbE, Intel® AMT, IEEE802.1AS, 802.3az

General

Power Consumption

90W (Typical @ 24V); 120W (Max. @ 24V)

90W (Typical @ 24V); 120W (Max. @ 24V)

90W (Typical @ 24V); 120W (Max. @ 24V)

Power Requirement

10~36 VDC

10~36 VDC

10~36 VDC

Mounting

Wall mount, Stand mount, Enclosure mount

Wall mount, Stand mount, Enclosure mount

Wall mount, Stand mount, Enclosure mount

OS Support

WIN7/8/10, WES7, Win10 Ent. LTSB, AdvLinuxTu

WIN7/8/10, WES7, Win10 Ent. LTSB, AdvLinuxTu

WIN7/8/10, WES7, Win10 Ent. LTSB, AdvLinuxTu

Weight (Net)

4.5 kg (9.9 lbs)

4.5 kg (9.9 lbs)

4.5 kg (9.9 lbs)

Form factor

Regular Size

Regular Size

Regular Size

Certifications

CE, UL, CCC, FCC, BSMI

CE, UL, CCC, FCC, BSMI

CE, UL, CCC, FCC, BSMI

Dimensions

142 x 238 x 177 mm (5.6'' x 9.3'' x 6.9'')

142 x 238 x 177 mm (5.6'' x 9.3'' x 6.9'')

142 x 238 x 177 mm (5.6'' x 9.3'' x 6.9'')
