Part Number

ARK-1123C-S3A2E

Processor

CPU

Intel Atom Processor E3825 Dual Core SoC

Core Number

2

Frequency

1.33 GHz

L2 Cache

1 MB

BIOS

AMI EFI 64 Mbit (Default BIOS is supported for 64-bit OS installation, BIOS for 32-bit OS is supported by project)

Memory

Technology

DDR3L 1066 MHz

Max. Capacity

8GB

Socket

1 x 204-pin SO-DIMM

Graphics

Chipset

Intel® Atom SoC integrated

Graphic Engine

DirectX* 11.1, OGL 3.0, OCL 1.1, OGL ES 2.0 Encode: H264, MPEG2/4, VC1, WMV9 Decode: H264, MPEG2

VGA

1 x VGA, support up to 1920 x 1200 at 60Hz

Audio

Main System

ALC-888S, High Definition Audio. Line-out & Line-in

Ethernet

LAN1

10/100/1000 Mbps Intel i210 GbE, support Wake On Lan

LAN2

10/100/1000 Mbps Intel I210 GbE, support Wake on LAN

I/O Interface

Serial Port

2 x RS-232/422/485 (BIOS selectable)

USB Interface

2 x USB 2.0 & 1 x USB3.0

Other

Watchdog Timer

255 levels timer interval, setup by software

Expansion

Mini PCIe

1 x Full-size Mini PCIe, support WLAN or WWAN module

Storage

2.5" Drive Bay

1 x 2.5” SATA HDD Bay (Max Height 9.5mm)

mSATA

1x Half-size mSATA (Suggest to assembly by CTOS or T-Part due to complex installation)

Software Support

Microsoft Windows

WES7, Windows 7, WE8S, Windows 8, Windows 10

Linux

Support (by Project)

Power

Input Voltage

12 VDC

Power Adaptor

AC to DC, DC12 V/3 A, 36 W with threaded design

Consumption

Typical 5.28 W, Max. 8.16 W

Mechanical

Construction

Aluminum housing

Mounting

VESA/DIN Rail/Wall Mounting Kits (Optional)

Dimensions

133.8 x 43.1 x 94.2 mm (5.27" x 1.7" x 3.71")

Weight

0.8kg

Environment

Operating Temperature

With extended temperature SSD/mSATA/RAM: -30 ~ 70° C with 0.7m/s air flow With standard temperature HDD/SSD/mSATA/RAM peripherals:0 ~ 40° C with 0.7m/s air flow

Storage Temperature

-40 ~ 85° C (-40~185° F)

Relative Humidity

95% @ 40° C (non-condensing)

Vibration during Operation

With mSATA/SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis With HDD: 0.5Grms, IEC 60068-2-64, random, 5~500Hz, 3 axes, 1hr/axis

Shock During Operation

With mSATA/SSD: 30 G, IEC 60068-2-27, half sine, 11 ms duration With HDD: 10G, IEC 60068-2-27, half sine, 11 ms duration

Regulation

EMC

CE/FCC Class B, CCC, BSMI

Safety

UL, CCC, BSMI, CB
