Part Number

AIMB-215D-S6B1E

AIMB-215L-S6B1E

AIMB-215N-S6B1E

AIMB-215U-S6B1E

Processor

CPU

Intel® Celeron® J1900

Intel® Celeron® J1900

Intel® Celeron® N2930

Intel® Celeron® N2807

Display

VGA

Up to 2560 x 1600

Up to 2560 x 1600

Up to 2560 x 1600

Up to 2560 x 1600

Multiple Display

Dual

Dual

Dual

Dual

LCD (TTL/LVDS/eDP)

LVDS: dual channel 24-bit up to 1920 x 1200

0

LVDS: dual channel 24-bit up to 1920 x 1200

0

DDI (HDMI/DVI/DisplayPort)

Display port 1.2 supports up to 2560 x 1600

Display port 1.2 supports up to 2560 x 1600

Display port 1.2 supports up to 2560 x 1600

Display port 1.2 supports up to 2560 x 1600

Ethernet

Controller

GbE LAN1: Realtek RTL8111E, GbE LAN2: Realtek RTL8111E

GbE LAN1: Realtek RTL8111E

GbE LAN1: Realtek RTL8111E, GbE LAN2: Realtek RTL8111E

GbE LAN1: Realtek RTL8111E

Audio

CODEC

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

I/O

COM Port

(5 x RS232,1 x RS232/ 422/ 485)

2 x RS232

(5 x RS232,1 x RS232/ 422/ 485)

2 (RS-232)

Expansion

Slots

1 x PCIex1, 2 x MiniPCIe

1 x PCIex1, 2 x MiniPCIe

1 x PCIex1, 2 x MiniPCIe

1 x PCIex1, 2 x MiniPCIe

PCI Express x 1

1

1

1

1
